China Plastics ›› 2022, Vol. 36 ›› Issue (7): 51-60.DOI: 10.19491/j.issn.1001-9278.2022.07.008
• Materials and Properties • Previous Articles Next Articles
GUO Yuwen, ZENG Bei, GAO Xing, WANG Pan(), REN Lianhai(
)
Received:
2022-02-23
Online:
2022-07-26
Published:
2022-07-20
CLC Number:
GUO Yuwen, ZENG Bei, GAO Xing, WANG Pan, REN Lianhai. Effect of PET microplastics on performance of co⁃digestion of sewage sludges and food wastes[J]. China Plastics, 2022, 36(7): 51-60.
Add to citation manager EndNote|Ris|BibTeX
URL: https://www.plaschina.com.cn/EN/10.19491/j.issn.1001-9278.2022.07.008
类别 | TS含量/% | VS含量/% | 碳氮比 | pH值 | 脂肪含量/% | 蛋白质含量/% |
---|---|---|---|---|---|---|
接种污泥 | 9.90±0.04 | 7.72±0.03 | 4.48±0.46 | 7.08±0.03 | 0.19±0.01 | 2.75±0.01 |
厨余垃圾 | 11.97±0.25 | 11.07±0.40 | 16.91±3.12 | 5.61±0.03 | 0.12±0.16 | 3.40±0.47 |
剩余污泥 | 14.15±0.03 | 5.67±0.81 | 5.16±0.53 | 7.06±0.12 | 0.12±0.02 | 3.69±0.14 |
类别 | TS含量/% | VS含量/% | 碳氮比 | pH值 | 脂肪含量/% | 蛋白质含量/% |
---|---|---|---|---|---|---|
接种污泥 | 9.90±0.04 | 7.72±0.03 | 4.48±0.46 | 7.08±0.03 | 0.19±0.01 | 2.75±0.01 |
厨余垃圾 | 11.97±0.25 | 11.07±0.40 | 16.91±3.12 | 5.61±0.03 | 0.12±0.16 | 3.40±0.47 |
剩余污泥 | 14.15±0.03 | 5.67±0.81 | 5.16±0.53 | 7.06±0.12 | 0.12±0.02 | 3.69±0.14 |
样品 | 物种数目 | 香农指数 | 辛普森多样性指数 | Chao指数 | ACE | |
---|---|---|---|---|---|---|
原始样品 | 原始混合样 | 642 | 5.555 | 0.931 | 750.010 | 0.763 |
第2天 | 对照组 | 445 | 3.877 | 0.822 | 507.658 | 521.905 |
250 μm | 458 | 4.257 | 0.848 | 479.798 | 500.598 | |
30 μm | 533 | 5.176 | 0.907 | 568.750 | 582.197 | |
第10天 | 对照组 | 531 | 6.020 | 0.955 | 537.443 | 547.914 |
250 μm | 311 | 4.964 | 0.940 | 330.588 | 328.870 | |
30 μm | 406 | 5.247 | 0.932 | 439.000 | 448.468 |
样品 | 物种数目 | 香农指数 | 辛普森多样性指数 | Chao指数 | ACE | |
---|---|---|---|---|---|---|
原始样品 | 原始混合样 | 642 | 5.555 | 0.931 | 750.010 | 0.763 |
第2天 | 对照组 | 445 | 3.877 | 0.822 | 507.658 | 521.905 |
250 μm | 458 | 4.257 | 0.848 | 479.798 | 500.598 | |
30 μm | 533 | 5.176 | 0.907 | 568.750 | 582.197 | |
第10天 | 对照组 | 531 | 6.020 | 0.955 | 537.443 | 547.914 |
250 μm | 311 | 4.964 | 0.940 | 330.588 | 328.870 | |
30 μm | 406 | 5.247 | 0.932 | 439.000 | 448.468 |
样品 | 物种数目 | 香农 指数 | 辛普森多样性指数 | Chao 指数 | |
---|---|---|---|---|---|
原始样品 | 原始混合样 | 93 | 2.559 | 0.698 | 94.000 |
第2天 | 对照组 | 107 | 2.094 | 0.644 | 114.800 |
250 μm | 62 | 1.593 | 0.432 | 62.000 | |
30 μm | 57 | 0.975 | 0.290 | 59.000 | |
第10天 | 对照组 | 114 | 1.876 | 0.546 | 116.000 |
250 μm | 89 | 1.401 | 0.397 | 90.600 | |
30 μm | 75 | 1.631 | 0.539 | 77.500 |
样品 | 物种数目 | 香农 指数 | 辛普森多样性指数 | Chao 指数 | |
---|---|---|---|---|---|
原始样品 | 原始混合样 | 93 | 2.559 | 0.698 | 94.000 |
第2天 | 对照组 | 107 | 2.094 | 0.644 | 114.800 |
250 μm | 62 | 1.593 | 0.432 | 62.000 | |
30 μm | 57 | 0.975 | 0.290 | 59.000 | |
第10天 | 对照组 | 114 | 1.876 | 0.546 | 116.000 |
250 μm | 89 | 1.401 | 0.397 | 90.600 | |
30 μm | 75 | 1.631 | 0.539 | 77.500 |
1 | 戴晓虎. 我国污泥处理处置现状及发展趋势[J]. 科学, 2020, 72(6): 30⁃34,4. |
DAI X H. Application and perspective of sludge treatment and disposal in China [J]. Science, 2020, 72(6): 30⁃34,4. | |
2 | Zhang Y C, Wu D, Su Y L, et al. Occurrence, influence and removal strategies of mycotoxins, antibiotics and microplastics in anaerobic digestion treating food waste and co⁃digestive biosolids: a critical review[J]. Bioresource Technology, 2021, 330: 124987. |
3 | Lajmanovich R C, Attademo A M, Lener G, et al. Glyphosate and glufosinate ammonium, herbicides commonly used on genetically modified crops, and their interaction with microplastics: Ecotoxicity in anuran tadpoles[J]. Science of The Total Environment, 2022, 804: 150177. |
4 | Cheng J, Ding L K, Lin R C, et al. Fermentative biohydrogen and biomethane co⁃production from mixture of food waste and sewage sludge: Effects of physiochemical properties and mix ratios on fermentation performance[J]. Applied Energy, 2016, 184: 1⁃8. |
5 | Zhang Z Q, Chen Y G. Effects of microplastics on wastewater and sewage sludge treatment and their removal: a review[J]. Chemical Engineering Journal, 2020, 382: 122955. |
6 | Van Wezel A, Caris I, Kools S A E. Release of primary microplastics from consumer products to wastewater in the Netherlands[J]. Environmental Toxicology and Chemistry, 2016, 35(7): 1 627⁃1 631. |
7 | Auta H S, Emenike C U, Fauziah S H. Distribution and importance of microplastics in the marine environment: A review of the sources, fate, effects, and potential solutions[J]. Environ Int, 2017, 102: 165⁃176. |
8 | Wei W, Huang Q S, Sun J, et al. Polyvinyl Chloride Microplastics Affect Methane Production from the Anaerobic Digestion of Waste Activated Sludge through Leaching Toxic Bisphenol⁃A[J]. Environmental Science & Techno⁃logy, 2019, 53(5): 2 509⁃2 517. |
9 | Wei W, Zhang Y T, Huang Q S, et al. Polyethylene terephthalate microplastics affect hydrogen production from alkaline anaerobic fermentation of waste activated sludge through altering viability and activity of anaerobic microorganisms[J]. Water Research, 2019, 163: 114881. |
10 | Tadsuwan K, Babel S. Microplastic abundance and removal via an ultrafiltration system coupled to a conventional municipal wastewater treatment plant in Thailand[J]. Journal of Environmental Chemical Engineering, 2022, 10(2): 107142. |
11 | Zhang J J, Wang L, Halden R U, et al. Polyethylene Terephthalate and Polycarbonate Microplastics in Sewage Sludge Collected from the United States[J]. Environmental Science & Technology Letters, 2019, 6(11): 650⁃655. |
12 | Wang P, Zheng Y, Lin P, et al. Effects of graphite, graphene, and graphene oxide on the anaerobic co⁃digestion of sewage sludge and food waste: attention to methane production and the fate of antibiotic resistance genes[J]. Bioresource Technology, 2021, 339: 125585. |
13 | Zhang Y T, Wei W, Huang Q S, et al. Insights into the microbial response of anaerobic granular sludge during long⁃term exposure to polyethylene terephthalate microplastics[J]. Water Research, 2020, 179: 115898. |
14 | 王 攀, 杜晓璐, 陈锡腾, 等. FeO对污泥接种餐厨垃圾厌氧发酵及抗生素抗性基因的影响[J]. 环境工程, 2019, 37(7): 178⁃182. |
WANG P, DU X L, CHEN X T, et al. Effects of FeO on biogas production and the fate of antibiotic resistance genes in anaerobic digestion of food waste inoculated with sludge [J]. Environmental Engineering, 2019, 37(7): 178⁃182 . | |
15 | Hobson P N, Shaw B G. Inhibition of methane production by Methanobacterium formicicum[J]. Water Research, 1976, 10(10): 849⁃852. |
16 | Zhao J W, Wang D B, Liu Y W, et al. Novel stepwise pH control strategy to improve short chain fatty acid production from sludge anaerobic fermentation[J]. Bioresource Technology, 2018, 249: 431⁃438. |
17 | Zhang J, Zhao M, Li C, et al. Evaluation the impact of polystyrene micro and nanoplastics on the methane generation by anaerobic digestion[J]. Ecotoxicology and Environmental Safety, 2020, 205: 111095. |
18 | Aydin S, Ince B, Ince O. Application of real⁃time PCR to determination of combined effect of antibiotics on bacteria, methanogenic archaea, archaea in anaerobic sequencing batch reactors[J]. Water Research, 2015, 76: 88⁃98. |
19 | Wu Q L, Guo W Q, Zheng H S, et al. Enhancement of volatile fatty acid production by co⁃fermentation of food waste and excess sludge without pH control: The mechanism and microbial community analyses[J]. Bioresource Technology, 2016, 216: 653⁃660. |
20 | Zeng T, Li L, Mo G, et al. Analysis of uranium removal capacity of anaerobic granular sludge bacterial communities under different initial pH conditions[J]. Environmental Science and Pollution Research, 2019, 26(6): 5 613⁃5 622. |
21 | Zeng D, Yin Q, Du Q, et al. System performance and microbial community in ethanol⁃fed anaerobic reactors acclimated with different organic carbon to sulfate ratios[J]. Bioresource Technology, 2019, 278: 34⁃42. |
22 | Miao L, Zhang Q, Wang S, et al. Characterization of EPS compositions and microbial community in an anammox SBBR system treating landfill leachate[J]. Bioresource technology, 2018, 249: 108⁃116. |
23 | Wang L, Wang L A, Zhan X, et al. Response mechanism of microbial community to the environmental stress caused by the different mercury concentration in soils[J]. Ecotoxicology and Environmental Safety, 2020, 188: 109906. |
24 | Lin X, Su C, Deng X, et al. Influence of polyether sulfone microplastics and bisphenol a on anaerobic granular sludge: performance evaluation and microbial community characterization[J]. Ecotoxicology and Environmental Safety, 2020, 205: 111318. |
25 | Reyna Gomez L M, Cruz Lopez A, Alfaro J M, et al. Evaluation of the production of biohydrogen during the co⁃digestion of organic wastes in an upflow hybrid anaerobic reactor[J]. Chemical Engineering Journal, 2021, 425:129235. |
26 | Arslan K, Veiga M C, Kennes C. Autotrophic (C1⁃gas) versus heterotrophic (fructose) accumulation of acetic acid and ethanol in Clostridium aceticum[J]. Bioresource Technology, 2021, 337:125484. |
27 | Wu Z, Nguyen D, Lam T Y C, et al. Synergistic association between cytochrome bd⁃encoded Proteiniphilum and reactive oxygen species (ROS)⁃scavenging methanogens in microaerobic⁃anaerobic digestion of lignocellulosic biomass[J]. Water Research, 2021, 190: 116721. |
28 | Wu Q, Ren W, Guo W, et al. Effect of substrate structure on medium chain fatty acids production and reactor microbiome[J]. Environmental Research, 2022, 204(A): 111947. |
29 | Yang G, Wang J, Zhang H, et al. Applying bio⁃electric field of microbial fuel cell⁃upflow anaerobic sludge blanket reactor catalyzed blast furnace dusting ash for promoting anaerobic digestion[J]. Water Research, 2019, 149: 215⁃224. |
30 | Nobu M K, Narihiro T, Kuroda K, et al. Chasing the elusive euryarchaeota class WSA2: genomes reveal a uniquely fastidious methyl⁃reducing methanogen[J]. ISME J, 2016, 10(10): 2 478⁃2 487. |
31 | Zhang L, Li F H, Kuroki A, et al. Methane yield enhancement of mesophilic and thermophilic anaerobic co⁃digestion of algal biomass and food waste using algal biochar: Semicontinuous operation and microbial community analysis[J]. Bioresource Technology, 2020, 302: 122892. |
