Application and Standard Interpretation of Graphite⁃modified Extruded Polystyrene Foam Boards for Thermal Insulation of Building

doi:10.19491/j.issn.1001-9278.2021.09.017

Abstract

Abstract:

Rigid extruded polystyrene foam boards are superior to other building insulation materials in many properties. They have excellent thermal insulation performance and a high ratio of performance to price. With an improvement in the fire protection standard for buildings， there a lot of new materials developed and emerged， resulting in a heavy competition of market. The market share of rigid extruded polystyrene foam boards has been occupied and reduced greatly. In order to maintain a market share and cope with the impact of new materials and the improvement of fire protection standard， graphite?modified extruded polystyrene foam boards have been developed by various research institutions and enterprises. Based on the development of JC/T 2627? 2021 “Graphite modified extruded polystyrene （GXPS） foam board for thermal insulation of building”， this paper introduced the main requirements for performance and application directions of GXPS boards and pointed out the product problems. This paper is expected to provide references for the subsequent research as well as the development of relevant standards.

Key words: graphite modification, rigid extruded polystyrene foam board, performance introduction, standard research

CLC Number:

TQ325.2

JIN Fujing, HAO Yunan, JIAO Hongwen, ZHAO Hongyu. Application and Standard Interpretation of Graphite⁃modified Extruded Polystyrene Foam Boards for Thermal Insulation of Building[J]. China Plastics, 2021, 35(9): 109-115.

Figures/Tables 12

References 4

1	李玲利，武薇，张金成，等.挤塑板吸水率检测方法的讨论［J］.中国建材科技， 2014（6）：1⁃4.
	LI L L， WU W， ZHANG J C， et al. Discussion of the Water Absorption Detection Method for Extruded Board［J］. China Building Materials Science & Technology， 2014（6）：1⁃4.
2	王勇，王向东，李莹.聚苯乙烯泡沫塑料（XPS）的主要性能及应用领域分析［J］.中国塑料，2011，25（8）：75⁃80.
	WANG Y， WANG X D， LI Y. Research on Properties and Applications of XPS Boards［J］.China Plastics， 2011，25（8）：75⁃80.
3	缪晓杰，周忠平，叶新.添加增强型石墨烯改善可发性聚苯乙烯性能的研究［J］.广东化工，2019，46（19）：62⁃71.
	LIAO X J， ZHOU Z P， YE X. Study on Adding Enhanced Graphene to Improve the Properties of Polystyren［J］. Guangdong Chemical Industry， 2019，46（19）：62⁃71.
4	王滢，任永，高新华，等.我国新增列持久性有机污染物的清单方法学研究［J］. 环境保护， 2016，44（15）： 46⁃51.
	WANG Y， REN Y， GAO X H， et al. The Inventory Methodology for Newly Listed Persistent Organic Pollutants in China［J］. Environmental Protection， 2016，44（15）： 46⁃51.

序号	出厂范围/kg·m^-3	实测结果/kg·m^-3
1	33~34	32
2	30~38	41
3	30~35	33
4	25~35	32
5	22~35	33

序号	出厂范围/kg·m^-3	实测结果/kg·m^-3
1	33~34	32
2	30~38	41
3	30~35	33
4	25~35	32
5	22~35	33

序号	尺寸稳定性/ %
序号	长度	宽度	厚度
1	-0.10	0.47	0.49
2	-0.16	1.92	0.54
3	-0.27	0.37	2.24
4	-0.01	-0.07	0.04
5	-0.08	-0.16	0.03
6	0.12	1.02	0.04
7	-0.27	0.94	-0.10
8	-0.50	0.02	0.52
9	-0.30	0.20	-0.28
10	-0.21	0.25	-0.14
11	0.60	0.60	0.40
12	0.9	0.9	0.6

序号	尺寸稳定性/ %
序号	长度	宽度	厚度
1	-0.10	0.47	0.49
2	-0.16	1.92	0.54
3	-0.27	0.37	2.24
4	-0.01	-0.07	0.04
5	-0.08	-0.16	0.03
6	0.12	1.02	0.04
7	-0.27	0.94	-0.10
8	-0.50	0.02	0.52
9	-0.30	0.20	-0.28
10	-0.21	0.25	-0.14
11	0.60	0.60	0.40
12	0.9	0.9	0.6

平均温度/℃	导热系数/W·（m·K）^-1
平均温度/℃	024级	030级	033级
10	≤0.022	≤0.028	≤0.032
25	≤0.024	≤0.030	≤0.034
