Pyrolysis mechanism and kinetics of calixarene based on TG analysis

doi:10.19491/j.issn.1001-9278.2022.01.014

Abstract

Abstract:

Thermogravimetry analysis was conducted to investigate the pyrolysis status and mechanism of calixarene and 4?tert?butylcalixarene under a nitrogen atmosphere. Meanwhile， the reaction activation energy and the optimal mechanism function equation of the two pyrolysis processes were obtained using a thermal decomposition kinetics method. The results indicated that the overall structure of 4?tert?butylcalixarene was more stable due to the strong interaction between the C—H σ and C＝C π bonds. Calixarene exhibited excellent char forming performance， and 4?tert?butylcalixarene presented an excellent thermal stability. Their decomposition temperatures are very suitable for the use of polymer materials， Moreover， the pyrolysis kinetic analysis demonstrated that the activation energies of calixarene were determined to be 179.14 and 192.84 kJ/mol through calculation using the Kissinger′s and Flynn?wall?Ozawa′s methods， respectively. The activation energies of 4?tert?butylcalixarene were calculated to be 291.61 and 312.14 kJ/mol using the Kissinger′s and Flynn?wall?Ozawa′s methods， respectively. According to the Coats?Redfern method， the pyrolysis mechanism function of calixarene was determined to be g（α）=［-ln（1-α）］^1/3 and its reaction order n was 1/3. Its non?isothermal pyrolysis mechanism belongs to random nucleation and subsequent growth reaction. The pyrolysis mechanism function of 4?tert?butylcalixarene was g（α）=α^1/3 and its reaction order n was 1/3.

Key words: calixarene, 4?tert?Butylcalix［8］arene, thermogravimetry, thermal decomposition, kinetics

CLC Number:

TQ314.2

ZHANG Dingran, LU Lingang. Pyrolysis mechanism and kinetics of calixarene based on TG analysis[J]. China Plastics, 2022, 36(1): 92-99.

Figures/Tables 13

References 15

1	GUTSCHE C D. Calixarenes：an introduction［M］. RSC Pub，2008：18⁃26.
2	龚淑玲，胡才仲，王巍，等.杯芳烃交联聚硅氧烷热稳定性能研究［J］.高分子学报，2006（1）：180⁃184.
	GONG S L， HU C Z， WANG W，et al. Thermal stability of calixarene crosslinked polysiloxane［J］. Acta polymer Sinica，2006（1）：180⁃184.
3	ZADMARD R， HOKMABADI F， JALALI M R， et al. Recent progress to construct calixarene⁃based polymers using covalent bonds： synthesis and applications［J］.RSC Advances， 2020， 10（54）： 32 690⁃32 722.
4	冯亚青，洪学传，李熙凤，等.对⁃叔丁基杯［4］芳烃对聚丙烯热氧稳定性的影响及其动力学研究［J］.高等学校化学学报，2001（3）：485⁃488.
	FENG Y Q， HONG X C， LI X F，et al. Effect of p⁃tert⁃butylcalix ［4］ arene on thermal oxidative stability of polypropylene and its kinetics［J］. Journal of chemistry of colleges and Universities， 2001（3）：485⁃488.
5	QIAN X D， ZHENG K S， LU L G， et al.A novel flame retardant containing calixarene and DOPO structures： Pre⁃paration and its application on the fire safety of polystyrene［J］. Polymers for advanced technologies， 2018 （29）：2 715⁃2 723.
6	LAZZAROTTO M， NACHTIGALL F F ， SCHNITZLER E ， et al. Thermo gravimetric analysis of supramolecular complexes of p⁃tert⁃butylcalix［6］arene and ammonium cations： crystal structure of diethylammonium complex［J］. Thermochimica Acta， 2005， 429（1）：111⁃117.
7	MARYAM S M， NIKJE M M A， RASOULI⁃SANIABAD M， et al. Synthesis and Characterization of Functionalized Calix［4］arene Derivatives and Preparation of Ri⁃gid Polyurethane Foams by the Incorporation of Calixarene［J］. Macromolecular Symposia， 2017， 373（1）：1600101.
8	NISHIKUBO T， KAMEYAMA A， KUDO H. Novel high performance materials. calixarene derivatives containing protective groups and polymerizable groups for photolithography， and calixarene derivatives containing active ester groups for thermal curing of epoxy resins［J］. Polymer Journal， 2003， 35（3）： 213⁃229.
9	GALINDO⁃GARCIA U ， TORRES L A. Crystal structure at the origin of the thermal stability and large enthalpy of fusion and sublimation values of calixarenes［J］. Crystal Growth & Design， 2020， 20（2）：1 302⁃1 310.
10	胡荣祖，高胜利，赵凤起，等.热分析动力学［M］.北京：科学出版社， 2001：99⁃101
11	刘振海，张洪林. 分析化学手册. 第8分册，热分析与量热学［M］. 化学工业出版社， 2012：23⁃26.
12	杨志骅.对叔丁基杯芳烃对聚丙烯性能的研究［J］.塑料工业，2011，39（7）：107⁃110.
	YANG Z H. Effect of p⁃tert⁃butyl calixarene on properties of polypropylene［J］. Plastics Industry， 2011，39（7）：107⁃110.
13	KISSINGER H E. Reaction kinetics in differential thermal analysis［J］. Analytical Chemistry， 1957， 29（11）：1 702⁃1 706.
14	OZAWA T. A new method of analyzing thermogravimetric data［J］. Bull Chem Soc Jpn， 1965， 38（11）：1 881⁃1 886.
15	COATS A W， REDFERN J P. Kinetic parameters from thermogravimetric data［J］. Nature， 1964， 201：68⁃69.

β/℃·min^-1	材料类别	T_{5 %}/℃	T_max/℃	R_max/%·℃^-1
10	杯［8］芳烃	257.09	348.69	0.645 9
10	对叔丁基杯［8］芳烃	408.00	413.37	2.266 7
20	杯［8］芳烃	266.79	360.58	0.544 0
20	对叔丁基杯［8］芳烃	410.07	421.40	1.571 5
30	杯［8］芳烃	334.51	369.05	0.518 9
30	对叔丁基杯［8］芳烃	413.28	424.90	1.263 2
40	杯［8］芳烃	303.50	372.00	0.482 0
40	对叔丁基杯［8］芳烃	414.13	432.14	0.857 1

β/℃·min^-1	材料类别	T_{5 %}/℃	T_max/℃	R_max/%·℃^-1
10	杯［8］芳烃	257.09	348.69	0.645 9
10	对叔丁基杯［8］芳烃	408.00	413.37	2.266 7
20	杯［8］芳烃	266.79	360.58	0.544 0
20	对叔丁基杯［8］芳烃	410.07	421.40	1.571 5
30	杯［8］芳烃	334.51	369.05	0.518 9
30	对叔丁基杯［8］芳烃	413.28	424.90	1.263 2
40	杯［8］芳烃	303.50	372.00	0.482 0
40	对叔丁基杯［8］芳烃	414.13	432.14	0.857 1

β/ ℃·min^-1	T_p/K	T_p^-1/ ×10^-3K^-1	ln（β/T_p²）/ K^-1·min^-1	E_K/ kJ·mol^-1
10	621.70	1.609	-10.562	179.14
20	633.59	1.578	-9.907
30	642.05	1.558	-9.528
40	645.00	1.550	-9.250

β/ ℃·min^-1	T_p/K	T_p^-1/ ×10^-3K^-1	ln（β/T_p²）/ K^-1·min^-1	E_K/ kJ·mol^-1
10	621.70	1.609	-10.562	179.14
20	633.59	1.578	-9.907
30	642.05	1.558	-9.528
40	645.00	1.550	-9.250

β/ ℃·min^-1	T_p/K	T_p^-1/ ×10^-3K^-1	ln（β/T_p²）/ K^-1·min^-1	E_K/ kJ·mol^-1
10	686.38	1.457	-10.760	291.61
20	694.41	1.440	-10.090
30	697.90	1.433	-9.695
40	705.14	1.418	-9.428
