China Plastics ›› 2022, Vol. 36 ›› Issue (2): 182-196.DOI: 10.19491/j.issn.1001-9278.2022.02.024
• Review • Previous Articles Next Articles
Received:
2021-08-16
Online:
2022-02-26
Published:
2022-02-23
CLC Number:
QIU Hongbo. Research progress in superhydrophobic wood surface based on bionic technology[J]. China Plastics, 2022, 36(2): 182-196.
类型 | 制备方法 | 优点 | 缺点 | 参考文献 |
---|---|---|---|---|
自上而下方法 | 自然基底模板法 | 基底材料来源广泛,操作简单,成本低 | 难以大规模生产,复制过程中结构易变形 | [ |
人工基底模板法 | 可大规模生产,操作方便,可重复使用 | 需要昂贵的刻蚀设备,剥离时容易破坏结构 | [ | |
等离子体刻蚀法 | 操作简单,表面均匀性好 | 设备比较昂贵,反应条件苛刻 | [ | |
化学刻蚀法 | 成本低,适合工业化生产,界面结合强度高 | 化学试剂污染环境,破坏基材结构、强度降低 | [ | |
自下而上方法 | 接枝共聚法 | 操作简单,性能稳定,耐久性好 | 耗时长,成本高,污染环境 | [ |
溶胶⁃凝胶法 | 各种体系已基本成熟,制备工艺简单, 反应条件温和,成本较低 | 溶胶和凝胶过程难以控制,溶液稳定性差 | [ | |
CVD法 | 实验参数可调控,制备的涂层更均匀精细 | 需要昂贵的设备、高温等反应条件,有毒和腐蚀性气体污染环境 | [ | |
浸涂、喷涂法 | 适合大面积生产,操作简单,成本低 | 需要专门的设备,涂层与基材附着强度差 | [ | |
层层自组装法 | 操作简便,组装程度、结构容易控制 | 耗时较长,制备效率低 | [ | |
水热法 | 制备原理简单,可通过调节反应条件控制材料的形貌和尺寸 | 需要专门的反应设备,对温度、压力要求高, 不适合大面积制备 | [ |
类型 | 制备方法 | 优点 | 缺点 | 参考文献 |
---|---|---|---|---|
自上而下方法 | 自然基底模板法 | 基底材料来源广泛,操作简单,成本低 | 难以大规模生产,复制过程中结构易变形 | [ |
人工基底模板法 | 可大规模生产,操作方便,可重复使用 | 需要昂贵的刻蚀设备,剥离时容易破坏结构 | [ | |
等离子体刻蚀法 | 操作简单,表面均匀性好 | 设备比较昂贵,反应条件苛刻 | [ | |
化学刻蚀法 | 成本低,适合工业化生产,界面结合强度高 | 化学试剂污染环境,破坏基材结构、强度降低 | [ | |
自下而上方法 | 接枝共聚法 | 操作简单,性能稳定,耐久性好 | 耗时长,成本高,污染环境 | [ |
溶胶⁃凝胶法 | 各种体系已基本成熟,制备工艺简单, 反应条件温和,成本较低 | 溶胶和凝胶过程难以控制,溶液稳定性差 | [ | |
CVD法 | 实验参数可调控,制备的涂层更均匀精细 | 需要昂贵的设备、高温等反应条件,有毒和腐蚀性气体污染环境 | [ | |
浸涂、喷涂法 | 适合大面积生产,操作简单,成本低 | 需要专门的设备,涂层与基材附着强度差 | [ | |
层层自组装法 | 操作简便,组装程度、结构容易控制 | 耗时较长,制备效率低 | [ | |
水热法 | 制备原理简单,可通过调节反应条件控制材料的形貌和尺寸 | 需要专门的反应设备,对温度、压力要求高, 不适合大面积制备 | [ |
树种 | 制备方法 | 疏水性试剂 | 接触角/(°) | 应用 | 文献 |
---|---|---|---|---|---|
桉木 | 溶胶⁃凝胶法 | 正硅酸乙酯/全氟癸基三氯硅烷 | 159 | 自清洁 | [ |
椴木 | 喷涂法 | SiO2/全氟癸基三乙氧基硅烷/环氧树脂 | 155 | 自清洁、热能存储 | [ |
杉木 | 浇筑法 | SiO2/全氟辛基三乙氧基硅烷 | 160 | 自清洁、耐久性防护层 | [ |
杉木 | 喷涂法 | 全氟烷基甲基丙烯酸共聚物/PDMS/TiO2 | 150 | 自清洁、耐久性防护层 | [ |
松木 | 浸渍法 | HDTMS/MTMS | 157.9 | 耐久性防护层 | [ |
椴木 | 浸渍法 | HDTMS/MTMS | 162.9 | 耐久性防护层 | [ |
未提到 | 化学沉积法 | Cu/AgNO3 | 160.5 | 耐久性防护层 | [ |
椴木 | 接枝共聚法 | 三氯甲基硅烷 | 153 | 油水分离 | [ |
巴尔沙木 | CVD法 | MTMS | 151 | 油水分离 | [ |
巴尔沙木 | 浸渍法 | 甲基丙烯酸甲酯/掺杂元素的铝锶化合物 | 162.8 | 智能窗户 | [ |
树种 | 制备方法 | 疏水性试剂 | 接触角/(°) | 应用 | 文献 |
---|---|---|---|---|---|
桉木 | 溶胶⁃凝胶法 | 正硅酸乙酯/全氟癸基三氯硅烷 | 159 | 自清洁 | [ |
椴木 | 喷涂法 | SiO2/全氟癸基三乙氧基硅烷/环氧树脂 | 155 | 自清洁、热能存储 | [ |
杉木 | 浇筑法 | SiO2/全氟辛基三乙氧基硅烷 | 160 | 自清洁、耐久性防护层 | [ |
杉木 | 喷涂法 | 全氟烷基甲基丙烯酸共聚物/PDMS/TiO2 | 150 | 自清洁、耐久性防护层 | [ |
松木 | 浸渍法 | HDTMS/MTMS | 157.9 | 耐久性防护层 | [ |
椴木 | 浸渍法 | HDTMS/MTMS | 162.9 | 耐久性防护层 | [ |
未提到 | 化学沉积法 | Cu/AgNO3 | 160.5 | 耐久性防护层 | [ |
椴木 | 接枝共聚法 | 三氯甲基硅烷 | 153 | 油水分离 | [ |
巴尔沙木 | CVD法 | MTMS | 151 | 油水分离 | [ |
巴尔沙木 | 浸渍法 | 甲基丙烯酸甲酯/掺杂元素的铝锶化合物 | 162.8 | 智能窗户 | [ |
1 | ZELINKS S L , KIRKER G T , BISHELL A B , et al . Effects of wood moisture content and the level of acetylation on brown rot decay[J]. Forests, 2020, 11(3): 1⁃10. |
2 | ALTGEN M , AWAIS M , ALTGEN D , et al . Distribution and curing reactions of melamine formaldehyde resin in cells of impregnation⁃modified wood[J]. Scientific Reports, 2020, 10(1): 1⁃10. |
3 | LIU M , GUO F , WANG H , et al . Highly stable wood material with low resin consumption via vapor phase furfurylation in cell walls[J]. ACS Sustainable Chemistry & Engineering, 2020, 8(37): 13 924⁃13 933. |
4 | BARTHLOTT W , NEINHUIS C . Purity of the sacred lotus, or escape from contamination in biological surfaces[J]. Planta, 1997, 202(1): 1⁃8. |
5 | FEI L , HE Z , LACOSTE J D , et al . A mini review on superhydrophobic and transparent surfaces[J]. The Chemical Record, 2020, 20(11): 1 257⁃1 268. |
6 | ERAL H B , OH J M . Contact angle hysteresis: a review of fundamentals and applications[J]. Colloid and polymer science, 2013, 291(2): 247⁃260. |
7 | BHATTACHARYYA R . Technological applications of superhydrophobic coatings: needs and challenges[D]. Bombay:Indian Institute of Technology, 2009. |
8 | WU Y , QIAN Z , LEI Y , et al . Superhydrophobic modification of cellulose film through light curing polyfluoro resin in situ[J]. Cellulose, 2018, 25(3): 1 617⁃1 623. |
9 | WEI D W , WEI H , GAUTHIER A C , et al . Superhydrophobic modification of cellulose and cotton textiles: Metho⁃dologies and applications[J]. Journal of Bioresources and Bioproducts, 2020, 5(1): 1⁃15. |
10 | 廖正芳,张伟,孟小琪,等 .基于单宁酸制备可喷涂超疏水材料[J].精细化工,2020,37(5):893⁃897,918. |
LIAO Z F , ZHANG W , MENG X Q , et al . Preparation of sprayable superhydrophobic materials based on tannic acid[J]. Fine Chemicals, 2020, 37(5):893⁃897,918. | |
11 | 王秋雨,乌日娜,王高升 .纤维素基超疏水材料的研究概况[J].中国造纸,2019,38(9):69⁃73. |
WANG Q Y , WU R N , WAN G S . Research progress of cellulose based super⁃hydrophobic materials[J]. China Pulp & Paper, 2019, 38(9): 69⁃73. | |
12 | YIN Y , HUANG R , ZHANG W , et al . Superhydrophobic⁃superhydrophilic switchable wettability via TiO2 photoinduction electrochemical deposition on cellulose substrate[J]. Chemical Engineering Journal, 2016, 289: 99⁃105. |
13 | XIE L , TANG Z , JIANG L , et al . Creation of superhydrophobic wood surfaces by plasma etching and thin⁃film deposition[J]. Surface and coatings technology, 2015, 281: 125⁃132. |
14 | TEISALA H , TUOMINEN M , KUUSIPALO J . Superhydrophobic coatings on cellulose⁃based materials: fabrication, properties, and applications[J]. Advanced Materials Interfaces, 2014, 1(1): 1300026. |
15 | YOUNG T. III . An essay on the cohesion of fluids[J]. Philosophical Transactions of the Royal Society of London, 1 805,95: 65⁃87. |
16 | WENZEL R N . Resistance of solid surfaces to wetting by water[J]. Industrial & Engineering Chemistry, 1936, 28(8): 988⁃994. |
17 | ZHU M , ZUO W , YU H , et al . Superhydrophobic surface directly created by electrospinning based on hydrophi⁃lic material[J]. Journal of materials science, 2006, 41(12): 3 793⁃3 797. |
18 | CASSIE A B D , BAXTER S . Wettability of porous surfaces[J]. Transactions of the Faraday society, 1944, 40: 546⁃551. |
19 | 朱朋辉,陈港,文执成 .超疏水纸张的制备及其应用的研究进展[J].造纸科学与技术,2017,36(1):40⁃45. |
ZHU P H , CHEN G , WEN Z C . Research progress in preparation and application of superhydrophobic papers[J]. Paper Science & Technology, 2017, 36(1): 40⁃45. | |
20 | 滕玉红, 王思佳, 葛梦晗,等 . 仿生超疏水表面的构建及应用研究进展[J]. 上海包装, 2018, 284(10):42⁃46. |
21 | SI Y , DONG Z , JIANG L . Bioinspired designs of superhydrophobic and superhydrophilic materials[J]. ACS central science, 2018, 4(9): 1 102⁃1 112. |
22 | JIN M , XING Q , CHEN Z . A review: natural superhydrophobic surfaces and applications[J]. Journal of Biomaterials and Nanobiotechnology, 2020, 11(2): 110. |
23 | JEEVAHAN J , CHANDRASEKARAN M , JOSEPH G B , et al . Superhydrophobic surfaces: a review on fundamentals, applications, and challenges[J]. Journal of Coa⁃tings Technology and Research, 2018, 15(2): 231⁃250. |
24 | SAS I , GORGA R E , JOINES J A , et al . Literature review on superhydrophobic self‐cleaning surfaces produced by electrospinning[J]. Journal of Polymer Science Part B: Polymer Physics, 2012, 50(12): 824⁃845. |
25 | 赵美蓉,周惠言,康文倩,等 .超疏水表面制备方法的比较[J].复合材料学报,2021,38(2):361⁃379. |
ZHAO M R , ZHOU H Y , KANG W Q , et al . Comparison of methods for fabricating superhydrophobic surface[J]. Acta Materiae Compositae Sinica,2021,38(2):361⁃379. | |
26 | GUAN H , HAN Z , CAO H , et al . Characterization of multi⁃scale morphology and superhydrophobicity of water bamboo leaves and biomimetic polydimethylsiloxane (PDMS) replicas[J]. Journal of Bionic Engineering, 2015, 12(4): 624⁃633. |
27 | 杨晓华,肖建华,欧军飞 .仿美人蕉微纳结构制备超疏水材料[J].中国塑料,2013,27(8):77⁃80. |
YANG X H , XIAO J H , OU J F . Preparation of super⁃hydrophobic material by imitating the micro⁃nano structure of canna leaf[J]. China Plastics, 2013, 27(8): 77⁃80. | |
28 | 杨玉山,沈华杰,邱坚 .基于模板印刷法的仿生超疏水木材的研制[J].西南林业大学学报(自然科学),2018,38(6):187⁃191. |
YANG Y S , SHEN H J , QIU J . Biomimetic superhydrophobic wood based on template imprint[J]. Journal of Southwest Forestry University, 2018, 38(6): 187⁃191. | |
29 | GHASEMLOU M , DAVER F , IVANOVA E P , et al . Bio⁃inspired sustainable and durable superhydrophobic materials: from nature to market[J]. Journal of Materials Chemistry A, 2019, 7(28): 16 643⁃16 670. |
30 | YANG Y , HE H , LI Y , et al . Using nanoimprint lithography to create robust, buoyant, superhydrophobic PVB/SiO2 coatings on wood surfaces inspired by red roses petal[J]. Scientific reports, 2019, 9(1): 1⁃9. |
31 | BAO W , LIANG D , ZHANG M , et al . Durable, high conductivity, superhydrophobicity bamboo timber surface for nanoimprint stamps[J]. Progress in Natural Science: Materials International, 2017, 27(6): 669⁃673. |
32 | ZHENG Z , ZENG Y , YAO R , et al . All⁃sputtered, flexi⁃ble, bottom⁃gate IGZO/Al2O3 bi⁃layer thin film transistors on PEN fabricated by a fully room temperature process[J]. Journal of Materials Chemistry C, 2017, 5(28): 7 043⁃7 050. |
33 | SUN J , BHUSHAN B . Nanomanufacturing of bioinspired surfaces[J]. Tribology International, 2019, 129: 67⁃74. |
34 | 解林坤,郑绍江,杜官本 .木材表面等离子体刻蚀和沉积碳氟薄膜的超疏水性[J].林业科学,2017,53(4):121⁃128. |
XIE L K , ZHENG S J , DU G B . The superhydrophobic properties for wood surfaces by plasma etching and deposition of fluorocarbon film[J]. Scientia Silvae Sinicae, 2017, 53(4): 121⁃128. | |
35 | CORTESE B , CASCHERA D , FEDERICI F , et al . Superhydrophobic fabrics for oil–water separation through a diamond like carbon (DLC) coating[J]. Journal of Materials Chemistry A, 2014, 2(19): 6 781⁃6 789. |
36 | KIM S , KIM K , JUN G , et al . Wood⁃nanotechnology⁃based membrane for the efficient purification of oil⁃in⁃water emulsions[J]. ACS nano, 2020, 14(12): 17 233⁃17 240. |
37 | WANG K , LIU X , TAN Y , et al . Two⁃dimensional membrane and three⁃dimensional bulk aerogel materials via top⁃down wood nanotechnology for multibehavioral and reusable oil/water separation[J]. Chemical Enginee⁃ring Journal, 2019, 371: 769⁃780. |
38 | ZHU Z , FU S , LUCIA L A . A fiber⁃aligned thermal⁃managed wood⁃based superhydrophobic aerogel for efficient oil recovery[J]. ACS Sustainable Chemistry & Engineering, 2019, 7(19): 16 428⁃16 439. |
39 | LEE S Y , RAHMAWAN Y , YANG S . Transparent and superamphiphobic surfaces from mushroom⁃like micropillar arrays[J]. ACS applied materials & interfaces, 2015, 7(43): 24 197⁃24 203. |
40 | WANG Y , TANG Z , LU S , et al . Superhydrophobic wood grafted by poly (2⁃(perfluorooctyl) ethyl methacrylate) via ATRP with self⁃cleaning, abrasion resistance and anti⁃mold properties[J]. Holzforschung, 2020, 74(8): 799⁃809. |
41 | DENG B , CAI R , YU Y , et al . Laundering durability of superhydrophobic cotton fabric[J]. Advanced Materials, 2010, 22(48): 5 473⁃5 477. |
42 | 巫龙辉,卢生昌,林新兴,等 .纤维素基超疏水材料的研究进展[J].林产化学与工业,2016,36(6):119⁃126. |
WU L H , LU S C , LIN X X , et al . Research progress in superhydrophobic cellulose⁃based materials[J]. Chemistry and Industry of Forest Products, 2016, 36(6): 119⁃126. | |
43 | SÈBE G , BROOK M A . Hydrophobization of wood surfaces: covalent grafting of silicone polymers[J]. Wood Science and Technology, 2001, 35(3): 269⁃282. |
44 | LIN W , HUANG Y , LI J , et al . Preparation of highly hydrophobic and anti⁃fouling wood using poly (methylhydrogen) siloxane[J]. Cellulose, 2018, 25(12): 7 341⁃7 353. |
45 | GAO J , LIN W , LIN S , et al . Environment⁃friendly and two⁃component method for fabrication of highly hydrophobic wood using poly (methylhydrogen) siloxane[J]. Polymers, 2021, 13(1): 124. |
46 | PRATIWI N , ARIEF S , WELLIA D V . Self⁃cleaning material based on superhydrophobic coatings through an environmentally friendly sol⁃gel method[J]. Journal of Sol⁃Gel Science and Technology, 2020, 96(3): 669⁃678. |
47 | 田根林,马欣欣,吕黄飞,等 .溶胶凝胶法制备超疏水竹材[J].东北林业大学学报,2015,43(2):84⁃86,97. |
TIAN G L , MA X X , LV H F , et al . Super⁃hydrophobic preparation for bamboo by sol⁃gel progress[J]. Journal of Northeast Forestry University, 2015, 43(2):84⁃86,97. | |
48 | LIU F , WANG S , ZHANG M , et al . Improvement of mechanical robustness of the superhydrophobic wood surface by coating PVA/SiO2 composite polymer[J]. Applied Surface Science, 2013, 280: 686⁃692. |
49 | TU K , WANG X , KONG L , et al . Fabrication of robust, damage⁃tolerant superhydrophobic coatings on naturally micro⁃grooved wood surfaces[J]. RSC Advances, 2016, 6(1): 701⁃707. |
50 | YANG Y , SHAN L , SHEN H , et al . Manufacturing of robust superhydrophobic wood surfaces based on PEG⁃functionalized SiO2/PVA/PAA/fluoropolymer hybrid transparent coating[J]. Progress in Organic Coatings, 2021, 154: 106186. |
51 | WANG H , ZHOU H , GESTOS A , et al . Robust, electro⁃conductive, self⁃healing superamphiphobic fabric prepared by one⁃step vapour⁃phase polymerisation of poly (3, 4⁃ethylenedioxythiophene) in the presence of fluorinated decyl polyhedral oligomeric silsesquioxane and fluorinated alkyl silane[J]. Soft Matter, 2013, 9(1): 277⁃282. |
52 | HUANG J , LYU S , FU F , et al . Green preparation of a cellulose nanocrystals/polyvinyl alcohol composite superhydrophobic coating[J]. RSC Advances, 2017, 7(33): 20 152⁃20 159. |
53 | YANG R , LIANG Y , HONG S , et al . Novel low⁃temperature chemical vapor deposition of hydrothermal delignified wood for hydrophobic property[J]. Polymers, 2020, 12(8): 1757. |
54 | 刘明,吴义强,卿彦,等 .木材仿生超疏水功能化修饰研究进展[J].功能材料,2015,46(14):14 012⁃14 018. |
LIU M , WU Y Q , QING Y , et al . Progress in the research of functional modification on bionic fabrication of superhydrophobic wood[J]. Journal of Functional Mate⁃rials, 2015, 46(14): 14 012⁃14 018. | |
55 | NIE K , XU L , QIAN T , et al . Fabrication of a robust and flame⁃retardant alooh⁃lignocellulose composite with a lotus⁃leaf⁃like superhydrophobic coating[J]. Journal of Wood Chemistry and Technology, 2020, 40(1): 44⁃57. |
56 | WANG F , LI S , WANG L . Fabrication of artificial super⁃hydrophobic lotus⁃leaf⁃like bamboo surfaces through soft lithography[J]. Colloids and Surfaces A: physicochemical and engineering aspects, 2017, 513: 389⁃395. |
57 | DAHLE S , MEUTHEN J , GUSTUS R , et al . Superhydrophilic coating of pine wood by plasma functionalization of self⁃assembled polystyrene spheres[J]. Coatings, 2021, 11(2): 114. |
58 | JANESCH J , ARMINGER B , GINDL⁃ALTMUTTER W , et al . Superhydrophobic coatings on wood made of plant oil and natural wax[J]. Progress in Organic Coa⁃tings, 2020, 148: 105891. |
59 | LIN L , CAO J , ZHANG J , et al . Enhanced anti⁃mold property and mechanism description of Ag/TiO2 wood⁃based nanocomposites formation by ultrasound⁃and vacuum⁃impregnation[J]. Nanomaterials, 2020, 10(4): 682. |
60 | ARMINGER B , GINDL⁃ALTMUTTER W , KECKES J , et al . Facile preparation of superhydrophobic wood surfaces via spraying of aqueous alkyl ketene dimer dispersions[J]. RSC Advances, 2019, 9(42): 24 357⁃24 367. |
61 | OU J , ZHAO G , WANG F , et al . Durable superhydrophobic wood via one⁃step immersion in composite silane solution[J]. ACS Omega, 2021, 6(11): 7 266⁃7 274. |
62 | ZHAO F , TANG T , HOU S , et al . Preparation and synergistic effect of chitosan/sodium Phytate/MgO nanoparticle fire⁃retardant coatings on wood substrate through layer⁃by⁃layer self⁃assembly[J]. Coatings, 2020, 10(9): 848. |
63 | WAN Y , HOU S , GUO M , et al . Surface properties of spray⁃assisted layer⁃by⁃layer electrostatic self⁃assembly treated wooden take⁃off board[J]. Applied Sciences, 2021, 11(2): 836. |
64 | GU H , ZHANG Q , GU J , et al . Facile preparation of superhydrophobic silica nanoparticles by hydrothermal⁃assis⁃ted sol⁃gel process and effects of hydrothermal time on surface modification[J]. Journal of Sol⁃Gel Science and Technology, 2018, 87(2): 478⁃485. |
65 | XING D , ZHANG Y , HU J , et al . Highly hydrophobic and self⁃cleaning heat⁃treated larix spp. Prepared by TiO2 and ZnO particles onto wood surface[J]. Coatings, 2020, 10(10): 986. |
66 | XIA M , YANG T , CHEN S , et al . Fabrication of superhydrophobic eucalyptus wood surface with self⁃cleaning performance in air and oil environment and high durability[J]. Colloid and Interface Science Communications, 2020, 36: 100264. |
67 | YANG H , WANG S , WANG X , et al . Wood⁃based composite phase change materials with self⁃cleaning superhydrophobic surface for thermal energy storage[J]. Applied Energy, 2020, 261: 114481. |
68 | WANG J , LU Y , CHU Q , et al . Facile construction of superhydrophobic surfaces by coating fluoroalkylsilane/silica composite on a modified hierarchical structure of wood[J]. Polymers, 2020, 12(4): 1⁃12. |
69 | TU K , WANG X , KONG L , et al . Facile preparation of mechanically durable, self⁃healing and multifunctional superhydrophobic surfaces on solid wood[J]. Materials & Design, 2018, 140: 30⁃36. |
70 | WANG N , WANG Q , XU S , et al . Robust superhydrophobic wood surfaces with mechanical durability[J]. Colloids and Surfaces A: Physicochemical and Engineering Aspects, 2021, 608: 125624. |
71 | ZHAO M , TAO Y , WANG J , et al . Facile preparation of superhydrophobic porous wood for continuous oil⁃water separation[J]. Journal of Water Process Engineering, 2020, 36: 101279. |
72 | GUAN H , CHENG Z , WANG X . Highly compressible wood sponges with a spring⁃like lamellar structure as effective and reusable oil absorbents[J]. ACS Nano, 2018, 12(10): 10 365⁃10 373. |
73 | AL⁃QAHTANI S , ALJUHANI E , FELALY R , et al . Development of photoluminescent translucent wood toward photochromic smart window applications[J]. Industrial & Engineering Chemistry Research, 2021, 60(23): 8 340⁃8 350. |
74 | HSIEH C T , CHANG B S , LIN J Y . Improvement of water and oil repellency on wood substrates by using fluorinated silica nanocoating[J]. Applied surface science, 2011, 257(18): 7 997⁃8 002. |
75 | LI J , LU Y , WU Z , et al . Durable, self⁃cleaning and superhydrophobic bamboo timber surfaces based on TiO2 films combined with fluoroalkylsilane[J]. Ceramics International, 2016, 42(8): 9 621⁃9 629. |
76 | YANG Y , SHEN H , QIU J . Fabrication of biomimetic robust self⁃cleaning superhydrophobic wood with canna⁃leaf⁃like micro/nanostructure through morph⁃genetic me⁃thod improved water⁃, UV⁃, and corrosion resistance properties[J]. Journal of Molecular Structure, 2020, 1219: 128616. |
77 | 王小青,孟军旺,程志泳,等 .木材耐久性超疏水表面构建研究进展[J].林业工程学报,2020,5(3):13⁃20. |
WANG X Q , MENG J W , CHENG Z Y , et al . Research progress of durable superhydrophobic wood surface[J]. China Forestry Science and Technology, 2020, 5(3): 13⁃20. | |
78 | ZHANG X , SI Y , MO J , et al . Robust micro⁃nanoscale flowerlike ZnO/epoxy resin superhydrophobic coating with rapid healing ability[J]. Chemical Engineering Journal, 2017, 313: 1 152⁃1 159. |
79 | JIA S , LU Y , LUO S , et al . Thermally⁃induced all⁃damage⁃healable superhydrophobic surface with photocatalytic performance from hierarchical BiOCl[J]. Chemical Engineering Journal, 2019, 366: 439⁃448. |
80 | JIN C , LI J , HAN S , et al . A durable, superhydrophobic, superoleophobic and corrosion⁃resistant coating with rose⁃like ZnO nanoflowers on a bamboo surface[J]. App⁃lied surface science, 2014, 320: 322⁃327. |
81 | LI J , SUN Q , YAO Q , et al . Fabrication of robust superhydrophobic bamboo based on ZnO nanosheet networks with improved water⁃, UV⁃, and fire⁃resistant properties[J]. Journal of Nanomaterials, 2015, 9: 1⁃9. |
82 | MA T , LI L , MEI C , et al . Construction of sustainable, fireproof and superhydrophobic wood template for efficient oil/water separation[J]. Journal of Materials Science, 2021, 56(9): 5 624⁃5 636. |
