人工智能在注射成型参数设置及优化中的研究进展

doi:10.19491/j.issn.1001-9278.2022.01.013

中国塑料 ›› 2022, Vol. 36 ›› Issue (1): 84-91.DOI: 10.19491/j.issn.1001-9278.2022.01.013

人工智能在注射成型参数设置及优化中的研究进展

郑方莉¹, 傅南红², 焦晓龙³, 杨卫民¹, 谢鹏程¹()

^1.北京化工大学机电工程学院，北京 100029
^2.宁波长飞亚塑料机械制造有限公司，浙江宁波 315000
^3.海天塑机集团有限公司，浙江宁波 315801

收稿日期:2021-06-17 出版日期:2022-01-26 发布日期:2022-01-21
基金资助:
大容量塑料内胆可靠性设计技术、可控成型与焊接工艺研究(2020YFB1506102)

Research progress in applications and optimization of artificial intelligence technology in injection molding parameters setting

ZHENG Fangli¹, FU Nanhong², JIAO Xiaolong³, YANG Weimin¹, XIE Pengcheng¹()

^1.College of Mechanical and Electrical Engineering，Beijing University of Chemical Technology，Beijing 100029，China
^2.Zhafir Ningbo Plastic Machinery Manufacturing Co，Ltd，Ningbo 315000，China
^3.Haitian Plastics Machinery Group Co，Ltd，Ningbo 315801，China

Received:2021-06-17 Online:2022-01-26 Published:2022-01-21
Contact: XIE Pengcheng E-mail:xiepc@mail.buct.edu.cn

摘要/Abstract

摘要：

对专家系统及案例推理、进化计算和机器学习这3类注射成型工艺参数设置及优化的人工智能技术发展现状进行了综述，并对今后的研究方向提出了建议。

关键词: 注射成型, 工艺参数设置, 工艺参数优化, 人工智能

Abstract:

In this paper， the development status of artificial intelligence technology for the three types （expert system and case?based reasoning， evolutionary computation and machine learning） of injection molding parameter setting and optimization was reviewed， and some suggestions for future research directions were proposed.

Key words: injection molding, process parameter setting, process parameter optimization, artificial intelligence

中图分类号:

TQ320.66⁺2

郑方莉, 傅南红, 焦晓龙, 杨卫民, 谢鹏程. 人工智能在注射成型参数设置及优化中的研究进展[J]. 中国塑料, 2022, 36(1): 84-91.

ZHENG Fangli, FU Nanhong, JIAO Xiaolong, YANG Weimin, XIE Pengcheng. Research progress in applications and optimization of artificial intelligence technology in injection molding parameters setting[J]. China Plastics, 2022, 36(1): 84-91.
