Study on migration behavior of phthalate esters from PVC cling films

doi:10.19491/j.issn.1001-9278.2023.08.012

Abstract

Abstract:

The migration of phthalate esters from cling films and their migration behavior to simulants were analyzed using the test method in accordance with GB 31604.30—2016. The effects of temperature， time， and food simulants on the migration behavior of phthalate esters were investigated. The results indicated that for all three commercially available food⁃grade poly（vinyl chloride）（PVC） cling films， the migration of di（2⁃ethylhexyl） phthalate （DEHP） was detected. For the same food simulant， the migration of DEHP in PVC cling films increased with an increase in temperature and time at different experimental temperatures and times. For different food simulants， the migration of DEHP in PVC cling films in oil simulants and high alcohol simulants was greater than that in aqueous and acid simulants at the same temperature and time.

Key words: phthalate, poly（vinyl chloride）, migration behavior, food simulant

CLC Number:

TQ325

ZHOU Yingxin, WENG Yunxuan, LYU Yihui. Study on migration behavior of phthalate esters from PVC cling films[J]. China Plastics, 2023, 37(8): 86-92.

Figures/Tables 7

References 25

1	GUZMAN P S， BENITEZ J J， HEREDIA G J A. Transparency of polymeric food packaging materials［J］. Food Research International， 2022， 161： 1⁃6.
2	Alias A R， Wan M K， Sarbon N M. Emerging materials and technologies of multi⁃layer film for food packaging application： A review［J］. Food Control， 2022， 136： 1⁃15.
3	AHMAD A A， SARBON N M. A comparative study： Physical， mechanical and antibacterial properties of bio⁃composite gelatin films as influenced by chitosan and zinc oxide nanoparticles incorporation［J］. Food Bioscience， 2021， 43： 1⁃7.
4	MENG W K， SUN H， SU G Y. Plastic packaging⁃associated chemicals and their hazards⁃An overview of reviews［J］. Science of The Total Environment， 2023， 651（2）： 3 253⁃3 268.
5	MEIKLE J， JONES K， CRESSWELL S L， et al. Assessment of the stable isotope ratio variability of cling films purchased in Australia［J］. Forensic Chemistry， 2023， 33： 1⁃5.
6	王笑妍，薛燕波，者东梅，等.邻苯二甲酸酯类增塑剂概况及法规标准现状［J］.中国塑料，2019，33（6）：95⁃105.
	WANG X Y， XUE Y B， ZHE D M， et al. Overview of phthalate plasticizers， current regulations and standards［J］. China Plastics， 2019， 33（6）：95⁃105.
7	Li H H， Yang Z B， Xu X X， et al. Pollution characteristics and health risk assessment of phthalate esters in household dust in Chengdu， China［J］. Human and Ecological Risk Assessment： An International Journal， 2022， 28（9）： 958⁃971.
8	EALES J， BETHEL A， GALLOWAY T， et al. Human health impacts of exposure to phthalate plasticizers： an overview of reviews［J］. Environment International， 2022， 158： 1⁃19.
9	SHOSHTARI Y， B， ZAREAN M， MANSOURIAN M， et al. Systematic review and meta⁃analysis on the association between phthalates exposure and insulin resistance［J］. Environmental Science and Pollution Research， 2019， 26：9 435⁃9 442.
10	REEVES K W， SANTANA M D， MANSON J E， et al. Predictors of urinary phthalate biomarker concentrations in postmenopausal women［J］. Environmental Research， 2019， 169：122⁃130.
11	QI Z， XIN Z C， XIN H， et al. The association between prenatal exposure to phthalates and cognition and neurobehavior of children⁃evidence from birth cohorts［J］. Neurotoxicology， 2019， 73：199⁃212.
12	BRASSEA P E， HERMANDEZ C J， LARTAGON M V， et al. Oxidative stress induced by phthalates in mammals： state of the art and potential biomarkers［J］. Environmental Research， 2022， 206： 1⁃12.
13	CHANG G P， BAECKKYOUNG S， Chang S R， et al. Mono⁃（2⁃ethylhexyl） phthalate induces oxidative stress and lipid accumulation in zebrafish liver cells［J］. Comparative Biochemistry and Physiology， Part C， 2020， 230： 1⁃6.
14	LI ZY， LIU H， LIU H， et al. Dietary exposure and risk assessment of phthalic acid esters through a total diet study in Shenzhen， South China［J］. Food Additives & Contaminants. Part A， 2022， 39（9）：1 591⁃1 603.
15	BUI T T， GIOVANOULIS G， COUSINS A P， et al. Human exposure， hazard and risk of alternative plasticizers to phthalate esters［J］. Science of the Total Environment， 2016， 541：451⁃467.
16	SILANO V， BARAT B J M， BOLOGNESI C， et al. Update of the risk assessment of di⁃butylphthalate （DBP）， butyl⁃benzyl⁃phthalate （BBP）， bis（2⁃ethylhexyl）phthalate （DEHP）， di⁃isononylphthalate （DINP） and diisodecylphthalate （DIDP） for use in food contact materials［J］. EFSA Journal， 2019， 17（12）： 5 838⁃5 920.
17	Commission European. Consolidated text： Commission Regulation （EU） No 10/2011 of 14 January 2011 on plastic materials and articles intended to come into contact with food ［EB/OL］. （2020⁃09⁃23）［2023⁃4⁃26］. .
18	焦逊，赵鹏，徐龙华，等. PVC保鲜膜中DEHP和DEHA向猪肉中迁移规律研究［J］. 北京工商大学学报（自然科学版）， 2018， 36（4）：55⁃60.
	JIAO X， ZHAO P， XU L H， et al. Migration behavior of DEHP and DEHA from PVC wrap to pork［J］. Journal of Food Science and Technology， 2018， 36（4）：55 -60.
19	BARP L， PURCARO G， FRANCHINA F A， et al. Determination of phthalate esters in vegetable oils using direct immersion solid⁃phase microextraction and fast gas chromatography coupled with triple quadrupole mass spectrometry［J］. Analytica Chimica Acta， 2015， 887：237⁃244.
20	FANG H， WANG J， LYNCH R. Migration of di（2⁃ethylhexyl）phthalate （DEHP） and di⁃n⁃butylphthalate （DBP） from polypropylene food containers［J］. Food Control， 2016， 73： 1 298⁃1 302.
21	ANDA F Y， CORDON C B A， GONZALEZ L A， et al. Effect of assay conditions on the migration of phthalates from polyvinyl chloride cling films used for food packaging in México［J］. Food Packaging and Shelf Life， 2021， 29（6）：1⁃8.
22	中华人民共和国国家卫生和计划生育委员会. 食品安全国家标准食品接触材料及制品邻苯二甲酸酯的测定和迁移量的测定：［S］. 北京：中国标准出版社， 2016.
23	中华人民共和国国家卫生和计划生育委员会. 食品安全国家标准食品接触材料及制品用添加剂使用标准：［S］. 北京：中国标准出版社， 2016.
24	中华人民共和国国家卫生和计划生育委员会. 食品安全国家标准食品接触材料及制品迁移试验预处理方法通则：［S］. 北京：中国标准出版社， 2016.
25	中华人民共和国国家卫生和计划生育委员会. 食品安全国家标准食品接触材料及制品迁移试验通则：［S］. 北京：中国标准出版社， 2015.

序号	化合物	线性方程	线性范围/mg•L^-1	LOD/mg•kg^-1	相关系数
1	DMP	y=3.71×10⁷x+3.30×10⁷	0.1~10	0.002 7	0.999 2
2	DEP	y=3.25×10⁷x+3.87×10⁷	0.1~10	0.002 5	0.999 2
3	DAP	y=2.25×10⁷x+6.99×10⁶	0.1~10	0.002 5	0.999 3
4	DIBP	y=3.83×10⁷x+4.89×10⁷	0.1~10	0.002 8	0.999 4
5	DBP	y=2.42×10⁷x+2.44×10⁹	0.1~10	0.002 4	0.999 5
6	DMEP	y=1.08×10⁷x-3.74×10⁶	0.1~10	0.002 5	0.999 3
7	BMPP	y=5.52×10⁷x+1.04×10⁷	0.1~10	0.002 4	0.999 2
8	DEEP	y=1.81×10⁷x-1.27×10⁷	0.1~10	0.002 5	0.999 1
9	DPP	y=1.23×10⁸x+6.77×10⁷	0.1~10	0.001 4	0.999 3
10	DHXP	y=6.59×10⁷x+7.58×10⁷	0.1~10	0.001 1	0.999 2
11	BBP	y=4.65×10⁷x+1.07×10⁷	0.1~10	0.001 3	0.999 2
12	DBEP	y=2.62×10⁷x-2.55×10⁷	0.1~10	0.001 5	0.999 0
13	DCHP	y=5.34×10⁷x-2.81×10⁷	0.1~10	0.002 2	0.999 4
14	DEHP	y=2.33×10⁵x+9.57×10⁵	0.1~10	0.002 4	0.999 6
15	DPhP	y=5.66×10⁷x+2.47×10⁷	0.1~10	0.001 5	0.999 3
16	DINP	y=5.94×10⁷x+1.31×10⁷	0.1~10	0.002 3	0.999 2
17	DNOP	y=6.37×10⁷x+1.50×10⁷	0.1~10	0.001 5	0.999 1
18	DNP	y=7.42×10⁷x-6.41×10⁷	0.1~10	0.002 6	0.999 0

序号	化合物	线性方程	线性范围/mg•L^-1	LOD/mg•kg^-1	相关系数
1	DMP	y=3.71×10⁷x+3.30×10⁷	0.1~10	0.002 7	0.999 2
2	DEP	y=3.25×10⁷x+3.87×10⁷	0.1~10	0.002 5	0.999 2
3	DAP	y=2.25×10⁷x+6.99×10⁶	0.1~10	0.002 5	0.999 3
4	DIBP	y=3.83×10⁷x+4.89×10⁷	0.1~10	0.002 8	0.999 4
5	DBP	y=2.42×10⁷x+2.44×10⁹	0.1~10	0.002 4	0.999 5
6	DMEP	y=1.08×10⁷x-3.74×10⁶	0.1~10	0.002 5	0.999 3
7	BMPP	y=5.52×10⁷x+1.04×10⁷	0.1~10	0.002 4	0.999 2
8	DEEP	y=1.81×10⁷x-1.27×10⁷	0.1~10	0.002 5	0.999 1
9	DPP	y=1.23×10⁸x+6.77×10⁷	0.1~10	0.001 4	0.999 3
10	DHXP	y=6.59×10⁷x+7.58×10⁷	0.1~10	0.001 1	0.999 2
11	BBP	y=4.65×10⁷x+1.07×10⁷	0.1~10	0.001 3	0.999 2
12	DBEP	y=2.62×10⁷x-2.55×10⁷	0.1~10	0.001 5	0.999 0
13	DCHP	y=5.34×10⁷x-2.81×10⁷	0.1~10	0.002 2	0.999 4
14	DEHP	y=2.33×10⁵x+9.57×10⁵	0.1~10	0.002 4	0.999 6
15	DPhP	y=5.66×10⁷x+2.47×10⁷	0.1~10	0.001 5	0.999 3
16	DINP	y=5.94×10⁷x+1.31×10⁷	0.1~10	0.002 3	0.999 2
17	DNOP	y=6.37×10⁷x+1.50×10⁷	0.1~10	0.001 5	0.999 1
18	DNP	y=7.42×10⁷x-6.41×10⁷	0.1~10	0.002 6	0.999 0

目标化合物	样品编号及材质
目标化合物	1^#PVC	2^#PVC	3^#PVC	4^#PVDC	5^#PVDC	6^#PE	7^#PE
DMP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DEP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DAP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DIBP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DBP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DMEP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
BMPP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DEEP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DPP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DHXP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
BBP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DBEP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DCHP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DEHP	1.36±0.62	0.29±0.02	0.44±0.02	0.17±0.01	n.d.	n.d.	0.15±0.01
DPhP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DINP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DNOP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DNP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.

目标化合物	样品编号及材质
目标化合物	1^#PVC	2^#PVC	3^#PVC	4^#PVDC	5^#PVDC	6^#PE	7^#PE
DMP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DEP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DAP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DIBP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DBP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DMEP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
BMPP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DEEP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DPP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DHXP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
BBP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DBEP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DCHP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DEHP	1.36±0.62	0.29±0.02	0.44±0.02	0.17±0.01	n.d.	n.d.	0.15±0.01
DPhP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DINP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DNOP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
DNP	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.	n.d.
