China Plastics ›› 2021, Vol. 35 ›› Issue (3): 151-160.DOI: 10.19491/j.issn.1001-9278.2021.03.020
• Review • Previous Articles
ZHU Wenyao1,2, SHAO Weiguang1, WANG Xinhua3, LI Hua1(), YE Haimu2, CAI Lihai1
Received:
2020-07-19
Online:
2021-03-26
Published:
2021-03-22
CLC Number:
ZHU Wenyao, SHAO Weiguang, WANG Xinhua, LI Hua, YE Haimu, CAI Lihai. Application Status and Development of Heat Temperature⁃Resistant Separator Materials for Lithium⁃ion Batteries[J]. China Plastics, 2021, 35(3): 151-160.
隔膜材料 | 耐热温度 | 制备工艺 | 特点 | 应用领域 | 生产厂商 |
---|---|---|---|---|---|
聚烯烃 | 到达135 ℃闭孔,150 ℃完全熔毁 | 拉伸 | 耐热温度低,闭孔后有可能熔毁,但生产与加工工艺简单,成本低 | 商品电池 | Celgard(美国)、上海恩捷(中国) |
改性聚烯烃 | 142 ℃闭孔,170 ℃熔毁 | 涂覆 | 耐热温度较PE有略微提升,闭孔后不熔毁,生产加工工艺简单 | 商品电池 | 住友(日本)、 帝人(日本) |
玻璃纤维 | 400 ℃以上长期工作 | — | 耐热温度高,电能损耗率低,但价格过高 | 实验室电极性能测试 | Whatman(英国) |
芳纶 | 250 ℃以上长期工作,410 ℃熔融 | 涂布、热压、 静电纺丝 | 力学性能、耐热性能、电解液湿润性高,生产效率低,价格较PE昂贵 | 动力电池 | Dupont(美国)、东燃(日本) |
聚酰亚胺 | 600 ℃热分解,无熔融 | 静电纺丝 | 力学性能、耐热性能、电解液湿润性高,生产效率低,价格较PE昂贵 | 动力电池 | Dupont(美国) |
聚对苯二甲酸乙二醇酯 | 210 ℃下长期工作 | 热压、涂布 | 耐热性能良好,尺寸稳定,生产工艺简单 | 动力电池 | Degussa(德国) |
聚醚醚酮 | 370 ℃下低收缩率 | 静电纺丝 | 力学性能、耐热性能高生产工艺复杂 | 动力电池 | — |
隔膜材料 | 耐热温度 | 制备工艺 | 特点 | 应用领域 | 生产厂商 |
---|---|---|---|---|---|
聚烯烃 | 到达135 ℃闭孔,150 ℃完全熔毁 | 拉伸 | 耐热温度低,闭孔后有可能熔毁,但生产与加工工艺简单,成本低 | 商品电池 | Celgard(美国)、上海恩捷(中国) |
改性聚烯烃 | 142 ℃闭孔,170 ℃熔毁 | 涂覆 | 耐热温度较PE有略微提升,闭孔后不熔毁,生产加工工艺简单 | 商品电池 | 住友(日本)、 帝人(日本) |
玻璃纤维 | 400 ℃以上长期工作 | — | 耐热温度高,电能损耗率低,但价格过高 | 实验室电极性能测试 | Whatman(英国) |
芳纶 | 250 ℃以上长期工作,410 ℃熔融 | 涂布、热压、 静电纺丝 | 力学性能、耐热性能、电解液湿润性高,生产效率低,价格较PE昂贵 | 动力电池 | Dupont(美国)、东燃(日本) |
聚酰亚胺 | 600 ℃热分解,无熔融 | 静电纺丝 | 力学性能、耐热性能、电解液湿润性高,生产效率低,价格较PE昂贵 | 动力电池 | Dupont(美国) |
聚对苯二甲酸乙二醇酯 | 210 ℃下长期工作 | 热压、涂布 | 耐热性能良好,尺寸稳定,生产工艺简单 | 动力电池 | Degussa(德国) |
聚醚醚酮 | 370 ℃下低收缩率 | 静电纺丝 | 力学性能、耐热性能高生产工艺复杂 | 动力电池 | — |
1 | HWANG K, KWON B, BYUN H. Preparation of PVDF Nanofiber Membranes by Electrospinning and Their Use as Secondary Battery Separators[J]. Journal of Membrane Science, 2011, 378(1/2):111⁃116. |
2 | ZHANG J, LIU Z, KONG Q, et al. Renewable and Superior Thermal⁃Resistant Cellulose⁃Based Composite Nonwoven as Lithium⁃ion Battery Separator[J]. ACS Applied Materials & Interfaces, 2013, 5(1):128⁃134. |
3 | 曹胜先. 锂离子电池隔膜研究与发展现状[J]. 塑料科技, 2013, 41(8):94⁃97. |
CAO S X. Research and Development of Lithium⁃ion Battery Separators[J]. Plastics Science and Technology, 2013, 41(8):94⁃97. | |
4 | 洪柳婷, 王 莉, 叶海木,等. 聚烯烃锂离子电池隔膜的研究进展[J]. 高分子通报, 2017(6):59⁃67. |
HONG L T,WANG L, YE H M,et al. Research Progress on Separators of Polyolefin Lithium Ion Battery[J]. Chinese Polymer Bulletin, 2017(6):59⁃67. | |
5 | 刘崇刚, 谭玲生, 史鹏飞. 锂离子电池的安全特性分析[J]. 电池工业, 2008, 13(2):78⁃81. |
LIU C G, TAN L S, SHI P F. Study on The Safety Performance of Li⁃ion Batteries[J]. Chinese Battery Industry, 2008, 13(2):78⁃81. | |
6 | 李 贺, 于申军, 陈志奎,等. 锂离子电池内部短路失效的反应机理研究[J]. 电化学, 2010, 16(2):185⁃190. |
LI H, YU S J, CHEN Z K, et al. Study on the Reaction Mechanism of Short Circuit Failure of Lithium Ion Battery[J]. Journal of Electrochemistry, 2010, 16(2):185⁃190. | |
7 | ZHENG H, QU Q, ZHANG L, et al. Hard Carbon a Promising Lithium⁃ion Battery Anode for High Temperature Applications with Ionic Electrolyte[J]. RSC Advances, 2012, 2(11):4 904. |
8 | ARUMUGAM D, KALAIGNAN G P. Electrochemical Characterizations of Surface Modified LiMn2O4 Cathode Materials for High Temperature Lithium Battery Applications[J]. Thin Solid Films, 2011, 520(1):338⁃343. |
9 | WANG J, WANG Y,GUO Y Z, et al. Electrochemical Characterization of AlPO4 Coated LiNi1/3Co1/3Mn1/3O2 Cathode Materials for High Temperature Lithium Battery Application[J]. Rare Metals, 2014:1⁃6. |
10 | ROBERTSON A D, WEST A R, RITCHIE A G. Review of Crystalline Lithium⁃ion Conductors Suitable For High Temperature Battery Applications[J]. Solid State Ionics, Diffusion & Reactions, 1997, 104(1⁃2):1⁃11. |
11 | 张 焱, 董浩宇, 刘杲珺,等. 动力锂离子电池复合隔膜研究进展[J]. 中国塑料, 2018, 32(5):15⁃27. |
ZHANG Y, DONG H Y, LIU G J, et al. Research Progress in Composite Separators For Power Lithium Ion Battery[J]. China Plastics, 2018, 32(5):15⁃27. | |
12 | JIANG W, LIU Z, KONG Q, et al. A High Temperature Operating Nanofibrous Polyimide Separator in Li⁃ion Battery[J]. Solid State Ionics, 2013, 232:44⁃48. |
13 | 王海文, 怀永建, 潘文成,等. 不同工艺制备的锂离子电池用隔膜的热性能[J]. 电池, 2012, 42(1):30⁃32. |
WANG H W, HUAI Y J, PAN W C, et al. Thermal Properties of Membranes for Lithium Ion Batteries Prepared by Different Processes[J]. Battery Bimonthly, 2012, 42(1):30⁃32. | |
14 | CHOI J W, AURBACH D. Promise and Reality of Post⁃Lithium⁃Ion Batteries with High Energy Densities[J]. Nature Reviews Materials, 2016, 1(4):1⁃16. |
15 | ARORA P, ZHANG Z. Battery Separators[J]. Chemical Reviews, 2004, 35(50):4 419⁃4 462. |
16 | 封志芳, 肖 勇, 温旭明,等. 锂离子电池隔膜技术研究进展[J]. 江西化工, 2019, 141(1):16⁃21. |
FENG Z F, XIAO Y, WEN X M, et al. Research Progress of Separator Technology of Lithium Ion Battery[J]. Jiangxi Chemical Industry, 2019, 141(1):16⁃21. | |
17 | 宋建龙, 解华华, 刘 俊,等. 涂层改性锂离子电池隔膜研究进展[J]. 信息记录材料, 2015, 16(4):52⁃57. |
SONG J L, XIE H H, LIU J, et al. Research Progress of Coating Modified Lithium Ion Battery Separators[J]. Information Recording Materials, 2015, 16(4):52⁃57. | |
18 | ZHANG X, JI L, TOPRAKCI O, et al. Electrospun Nanofiber⁃Based Anodes, Cathodes, and Separators for Advanced Lithium⁃Ion Batteries[J]. Polymer Reviews, 2011, 51(3):239⁃264. |
19 | AVDEEV I, MARTINSEN M, FRANCIS A. Rate⁃ and Temperature⁃Dependent Material Behavior of a Multilayer Polymer Battery Separator[J]. Journal of Materials Engineering and Performance, 2014, 23(1):315⁃325. |
20 | 莫名月, 陈红雨. 锂离子电池隔膜的研究进展[J]. 电源技术, 2011, 35(11):1 438⁃1 440. |
MO M Y, CHEN H Y. Research Progress on Separator Materials for Lithium⁃ion Batteries[J]. Chinese Journal of Power Sources, 2011, 35(11):1 438⁃1 440. | |
21 | 黄友桥, 管道安. 锂离子电池隔膜材料的研究进展[J]. 船电技术, 2011, 31(1):26⁃29. |
HUANG Y Q, GUAN D A. Recent Development of the Separator for Lithium Ion Battery[J]. Marine Electric Electronic Technology, 2011, 31(1):26⁃29. | |
22 | 君岛康太郎, 开米教充. 聚烯烃微多孔膜及其制造方法、以及电池用隔离件和电池:CN101313016 A[P]. 2011⁃09⁃28. |
23 | 菊地慎太郎, 泷田耕太郎. 聚烯烃多层微孔膜及其制造方法以及电池用隔离件:CN101296795 A[P]. 2008⁃10⁃29. |
24 | CHUNG Y S, YOO S H, KIM C K. Enhancement of Meltdown Temperature of the Polyethylene Lithium⁃Ion Battery Separator via Surface Coating with Polymers Having High Thermal Resistance[J]. Industrial & Engineering Chemistry Research, 2009, 48(9):4 346⁃4 351. |
25 | 温 敏, 巫晓鑫, 曾 钫,等. 锂电池隔膜母料用改性高密度聚乙烯的制备及性能研究[J]. 塑料工业, 2013, 41(9):118⁃121. |
WEN M, WU X X, ZENG F, et al. Preparation and Performance of Cross⁃linking HDPE as Masterbatch for Lithium Battery Separator[J]. China Plastics Industry, 2013, 41(9):118⁃121. | |
26 | 程 跃, 陈 辉, 邓洪贵. 一种锂离子电池隔膜浆料及其制备方法和锂离子电池隔膜: CN 109585757 A[P]. 2019⁃04⁃05. |
27 | 程 跃, 张祖来, 苏晓明,等. 一种锂离子电池隔膜的制备方法: CN105552280A[P]. 2016⁃05⁃04 |
28 | 徐 健, 何林莉, 景希玮,等. 氧化铝/丙烯酸酯乳液改性聚乙烯隔膜的制备及性能[J]. 精细化工, 2019(7):1 321⁃1 325. |
XU J, HE L L, JING X W, et al. Preparation and Properties of Al2O3/Acrylate Emulsion Modified Polyethylene Separators[J]. Fine Chemicals, 2019(7):1 321⁃1 325. | |
29 | LUI, CHRIS. Teijin Launches Fluorine⁃based Lithium⁃ion Battery Separators[N]. JCNN News Summaries⁃Japan Corporate News Network, 2012⁃02⁃07. |
30 | 樱井博志, 西川聪, 赤松哲也. 非水系二次电池用隔膜及非水系二次电池: CN109390533A[P]. 2019⁃02⁃26. |
31 | 住友化学锂离子电池隔膜产能将扩大2.3倍[J]. 信息记录材料, 2014(3):28. |
32 | 刘春娜. 锂电池隔膜行业发展动态[J]. 电源技术, 2015(4):657⁃658. |
LIU C N. Development Trend of Lithium Battery Separator Industry[J]. Chinese Journal of Power Sources, 2015(4):657⁃658. | |
33 | 长谷川博彦, 西田裕纪, 筱原泰雄. 层叠多孔质膜及制造方法、非水电解液二次电池用隔膜、层叠电极片和非水电解液二次电池:CN109378428A[P]. 2019⁃02⁃22. |
34 | 尹艳红, 毛新欣, 曹朝霞,等. 相转化法制备陶瓷涂层改性锂离子电池隔膜[J]. 功能高分子学报, 2012, 25(2):69⁃74. |
YIN Y H, MAO X X, CAO Z X, et al. Modification if Lithium Ion Battery Separator with Ceramic Coating Using Phase Invertion[J]. Journal of Functional Polymers, 2012, 25(2):69⁃74. | |
35 | 崔巍巍, 孟庆朋, 王振宇,等. 大倍率高耐热聚醚酰亚胺⁃聚偏氟乙烯芯壳纳米纤维锂离子电池隔膜[J]. 复合材料学报, 2019, 36(1):75⁃82. |
CUI W W, MENG Q P, WANG Z Y, et al. A High Rate and Heat⁃resistant Polyether Imide⁃polyvinylidene Fluoride Core⁃shell Nanofiber Separator for Lithium⁃ion Battery[J]. Acta Materiae Compositae Sinica, 2019, 36(1):75⁃82. | |
36 | GONG W, GU J, RUAN S, et al. A High⁃strength Electrospun PPESK Fibrous Membrane for Lithium⁃ion Battery Separator[J]. Polymer Bulletin, 2019, 76(10):5 451⁃5 462. |
37 | 新材料在线.2020年锂电池隔膜行业研究报告[R/OL] [2020⁃07⁃18] ?id=575 605. |
38 | GUIDOTTI R A, REINHARDT F W. Evaluation of Fiber Separators for Use in Thermal Batteries[R]. Office of Scientific & Technical Information Technical Reports, 1999. |
39 | JIA H, STOCK C, KLOEPSCH R, et al. Facile Synthesis and Lithium Storage Properties of a Porous NiSi2/Si/carbon Composite Anode Material for Lithium⁃ion Batteries[J]. ACS Applied Materials & Interfaces, 2015, 7(3):1508. |
40 | ARAVINDAN V, KUMAR P S,SUNDARAMURTHY J, et al. Electrospun NiO Nanofibers as High Performance Anode Material for Li⁃ion Batteries[J]. Journal of Power Sources, 2013, 227(4):284⁃290. |
41 | WU Y, WANG F, LI X, et al. Fabrication of a Graphene Oxide/nanoscale Aramid Fiber Composite Membrane with Improved Hydrophilicity and Mechanical Strength via a Fast⁃drying Method Using Absolute Ethanol as Proton Donor[J]. Journal of Materials Science, 2018, 53(24): 16 383⁃16 392. |
42 | 杨 兵, 惠岚峰. 特种芳纶纤维在造纸中的应用[J]. 中华纸业, 2019(4):6⁃10. |
YANG B, HUI L F. Application of Aramid Fiber in Specialty Paper Production[J]. China Pulp Paper Industry, 2019(4):6⁃10. | |
43 | 前瞻产业研究院. 2019年中国芳纶产品行业竞争格局与发展前景分析⁃中国间位芳纶市场未来发展可期[R/OL] [2020⁃07⁃09] . |
44 | 丁海兵. 对位芳纶国内外市场需求与产业化现状[J]. 合成纤维工业, 2013, 36(4):49⁃51. |
DING H B. The Market Demand and Industrialization Status of Aramid Fiber at Home and Abroad[J]. China Synthetic Fiber Industry, 2013, 36(4):49⁃51. | |
45 | ZHANG J, KONG Q, LIU Z, et al. A Highly Safe and Inflame Retarding Aramid Lithium Ion Battery Separator by a Papermaking Process[J]. Solid State Ionics, 2013, 245: 49⁃55. |
46 | 陆赵情,张美云,王志杰,等. 芳纶纸基复合材料研究进展及关键技术[J]. 宇航材料工艺, 2006(6):5⁃8. |
LU Z Q, ZHANG M Y, WANG Z J, et al. Progress and Technological Key of High Performance Aramid Paper Reinforced Composites[J]. Aerospace Materials Technology, 2006(6):5⁃8. | |
47 | 沢本敦司, 西原健太, 佃明光. 芳香族聚酰胺多孔膜、电池用隔膜及电池:CN104053714A[P]. 2014⁃09⁃07. |
48 | ZHANG J, KONG Q, LIU Z, et al. A Highly Safe and Inflame Retarding Aramid Lithium Ion Battery Separator by a Papermaking Process[J]. Solid State Ionics, 2013, 245:49⁃55. |
49 | LI J, TIAN W, YAN H, et al. Preparation and Performance of Aramid Nanofiber Membrane for Separator of Lithium Ion Battery[J]. Journal of Applied Polymer Science, 2016, 133(30):43623. |
50 | 何小芳, 韩雪鹏, 秦 刚,等. 聚酰亚胺(PI)锂离子电池隔膜材料的研究进展[J]. 塑料工业, 2016, 44(1):1⁃4. |
HE X F, HAN X P, QIN G, et al. Research Progress of Polyimide Diaphragm Material for Lithium Ion Battery[J]. China Plastics Industry, 2016, 44(1):1⁃4. | |
51 | 安 平. 聚酰亚胺锂离子电池隔膜的制备及其性能研究[D]. 西安:陕西科技大学,2015. |
52 | 闫薪竹, 关士友. 锂离子电池用聚酰亚胺黏结剂和隔膜的制备及相关性能的研究[J]. 塑料工业, 2016, 44(8):125⁃128. |
YAN X Z, GUAN S Y. Preparation and Properties of Polyimide Binder and Separator for Lithium Ion Battery[J]. China Plastics Industry, 2016, 44(8):125⁃128. | |
53 | 智研咨询.2017年全球聚酰亚胺行业产量统计分析[DB/OL][2020⁃07⁃09] . |
54 | 新材料在线.2019年聚酰亚胺(PI)行业研究报告[R/OL] [2020⁃07⁃09]?id=561861&ptype=1. |
55 | HUANG Z M, ZHANG Y Z, KOTAKI M, RAMAKRISHNA S. A Review on Polymer Nanofibers by Electrospinning and Their Applications in Nanocomposites[J]. Composites Science and Technology, 2003, 63(15): 2 223⁃2 253. |
56 | XUE J, WU T, DAI Y, et al. Electrospinning and Electrospun Nanofibers: Methods, Materials, and Applications[J]. Chemical Reviews, 2019, 119(8): 5 298⁃5 415. |
57 | KIM Y, WU X, OH J H. Fabrication of Triboelectric Nanogenerators Based on Electrospun Polyimide Nanofibers Membrane[J]. Scientific Reports, 2020, 10(1): 1⁃9. |
58 | 王姝瑛, 李 敏, 龚光明,等. 静电纺丝制备具有浸润性梯度的聚酰亚胺纳米纤维膜[J]. 高等学校化学学报, 2012, 33(5): 1 090⁃1 094. |
WANG S Y, LI M, GONG G M, et, al. Preparation of Polyimide Nanofiber Membrane with Gradient Wettability by Electrospinning [J]. Chemical Journal of Chinese Universities, 2012, 33(5): 1 090⁃1 094. | |
59 | 伯 章. 杜邦公司开发锂离子电池用聚酰亚胺隔膜[J]. 国外塑料, 2010, 28(9):67. |
60 | 丹尼斯T J,马祖尔S. 具有酰胺化表面的聚酰亚胺纳米纤维网及制备方法:CN103261502A[P]. 2016⁃01⁃13. |
61 | ZHAN J, TIAN G, QI S, et al. Fabrication and Mechanism Study of CuO Layers on Double Surfaces of Polyimide Substrate Using Surface Modification[J]. Composites Science and Technology, 2012, 72(9):1 020⁃1 026. |
62 | MIAO Y E, ZHU G N, Hou H, et al. Electrospun Polyimide Nanofiber⁃based Nonwoven Separators for Lithium⁃ion Batteries[J]. Journal of Power Sources, 2013, 226:82⁃86. |
63 | HAO J, LEI G, LI Z, et al. A Novel Polyethylene Terephthalate Nonwoven Separator Based on Electrospinning Technique for Lithium Ion Battery[J]. Journal of Membrane Science, 2013, 428:11⁃16. |
64 | 2018年中国非织造布市场发展现状及趋势分析[R/OL] [2020⁃07⁃09] . |
65 | XIA L, ZHANG Q, ZHUANG X, et al. Hot⁃pressed Wet⁃laid Polyethylene Terephthalate Nonwoven as Support for Separation Membranes[J]. Polymers, 2019, 11(10): 1 547. |
66 | KURIYAMA I, SHIRAKASHI K. Thermal Shrinkage Behavior of the Heated Polyethylene Terephthalate Fibers [J]. Sen'i Gakkaishi, 1964, 20(6): 347⁃355. |
67 | 王振华, 彭代冲, 孙克宁. 锂离子电池隔膜材料研究进展[J]. 化工学报, 2018, 69(1):282⁃294. |
WANG Z H, PENG D C, SUN K N. Research Progress of Separator Materials for Lithium Ion Batteries[J]. CIESC Jorunal, 2018, 69(1):282⁃294. | |
68 | HENNIGE V, HYING C, HOERPEL G. Electrical Separator, Method for Making Same and Use Thereof in High⁃power Lithium Cells: US20050255769A1[P].2005⁃11⁃17. |
69 | ZHAO Z, WANG D, YU L, et al. Preparation and Property of High Heat⁃Resistant Ceramic Composited PET Separator[C]//Proceedings of SAE⁃China Congress 2014:Selected Papers:2014. |
70 | YE H M, ZHU W Y, LIU P, et al. Fabrication of Shrinkage⁃free Poly (Ether Ether Ketone) Nanofibrous Mat and Its Use For Flexible and Thermally⁃recycled MOF Composites[J]. Materials Today Communications, 2020, 23: 100862. |
71 | PATEL P, HULL T R, MCCABE R W, et al. Mechanism of Thermal Decomposition of Poly (Ether Ether Ketone)(PEEK) from a Review of Decomposition Studies[J]. Polymer Degradation and Stability, 2010, 95(5): 709⁃718. |
72 | SHUKLA D, NEGI Y S, UPPADHYAYA J S, et al. Synthesis and Modification of Poly (Ether Ether Ketone) and Their Properties: a Review[J]. Polymer Reviews, 2012, 52(2): 189⁃228. |
73 | 张 丽. 聚醚醚酮市场分析及发展趋势[J]. 化工新型材料, 2020, 48(5): 1⁃6. |
ZHANG L. Analysis and Development Trend of PEEK Market[J]. New Chemical Materials, 2020, 48(5): 1⁃6. | |
74 | DEVAUX J,DELIMOY D, DAOUST D, et al. On the Molecular Weight Determination of a Poly (Aryl⁃ether⁃ether⁃ketone)(PEEK)[J]. Polymer, 1985, 26(13): 1 994⁃2 000. |
75 | LOVINGER A J, DAVIS D D. Solution Crystallization of Poly (Ether Ether Ketone)[J]. Macromolecules, 1986, 19(7): 1 861⁃1 867. |
76 | SHAM C K, GUERRA G, KARASZ F E, et al. Blends of Two Poly (Aryl Ether Ketones)[J]. Polymer, 1988, 29(6): 1 016⁃1 020. |
77 | XU J, ZHANG Z, XIONG X, et al. A New Solvent for Poly (Ether Ether Ketone)[J]. Polymer, 1992, 33(20): 4 432⁃4 434. |
